Overview

Place of Origin: Henan, China (Mainland) Product name: Varable frequency cable Rand Name: YILAN

Model Number: BPYJVP/BPYJVP2 Application:Industrial Conductor Material: copper

Conductor Type: solid/stranded Rated voltage: 0.6/1KV Insulation Material: XLPE/PVC Certificate: ISO9001/OHSAS18001/CCC MOQ: 500Meter Jacket: pvc

Warranty: 5-10 Years.

Our wire and cable use 100% oxygen-free copper as conductor according to international standard.The hardness of cables is high,and the outer sheath is corrosion-resistant with the longest time.The cables'reasonable life span is over 20 years.We not only sell the product,the brand'influence is more important for our campany.

Application:

The cable is used as power supply cables or electrical connection of inverter control system at AC rated voltage 0.6/1KV or less

Working Condition:

1.AC rated voltage Uo/U:0.6/1KV

2.Max working temperature PVC insulation is 70ºC,XLPE insulation is 90ºC

3.Min. enviroment temperature XLPE sheathed cable shall be not less than -70ºC ,PVC sheath cable shall be not less than -25ºC

4.Enviroment temperature shall be not less than 0ºC for cable in-stallation.

5.Min.bending radius for installation shall be 15 times outer diameter of cable.

Type and Name:

JUST LISTED PART OF PRODUCTS, CONTACT US FOR MORE INFORMATION
